1、Ifusedinconjunctionwithpowercablebridging,powerandweakcurrentcablesshallbeseparatedoneachstraightedgebymeansofintermediatebarriers.Cabletraymanufacturer

    二、基本情況

    2、Basicinformation

    （1）荷載計算：計算索橋干線斷面上單位長度的索重。

    (1)Loadcalculation:calculatethecableweightperunitlengthonthemainsectionofthecablebridge.

    （2）確定方向：根據建筑平面布置圖，結合空調管道、電氣管道的設置，維修方便，電纜線路密度，確定電纜橋架的更佳線路。在室內，應盡量沿建筑物的墻、柱、梁、樓板搭設。如果可以利用綜合管廊架設，應在管的一側或上方平行架設，并考慮引下線和支線盡量避免交叉。如果沒有其他管架可供借用，則需自行設置（支撐）柱。

    (2)Determinethedirection:accordingtothelayoutplanofthebuilding,combinedwiththesettingofairconditioningpipesandelectricalpipes,convenientmaintenance,cablelinedensity,determinethebestlineofcablebridge.Indoors,itshouldbebuiltalongthewall,column,beamandfloorofthebuildingasfaraspossible.Iftheutilitytunnelcanbeusedforerection,itshallbeerectedinparallelononesideorabovethepipe,andthedownleadandbranchlineshallbeconsideredtoavoidcrossingasmuchaspossible.Ifthereisnootherpipesupportavailableforborrowing,itisnecessarytoset(support)thecolumnbyitself.

    （3）確定橋梁寬度：根據鋪設的電纜數量、電纜直徑和電纜間距，確定電纜橋架的型號和規格、支臂長度、支柱長度和間距、橋架的寬度和層數。

 (3)Determinethebridgewidth:accordingtothenumberofcableslaid,cablediameterandcablespacing,determinethemodelandspecificationofthecablebridge,thelengthofthearm,thelengthandspacingofthecolumn,thewidthandnumberoflayersofthebridge.

    （4）繪制電纜橋架的平面圖和剖面圖，繪制空間圖，列出部分零件的材料表。

    (4)Drawtheplanandsectionofthecabletray,drawthespacemap,andlistthematerialtableofsomeparts.

    （5）確定安裝方式：根據場地的設置條件確定橋梁的固定方式，選擇懸掛式、垂直式、側墻式或混合式。通常，連接器和緊固件一起提供。另外，根據橋梁結構選擇相應的蓋板。

 (5)Determinetheinstallationmode:determinethefixedmodeofthebridgeaccordingtothesitesettingconditions,andselectthesuspensiontype,verticaltype,sidewalltypeorhybridtype.Generally,connectorsaresuppliedwithfasteners.Inaddition,thecorrespondingcoverplateisselectedaccordingtothebridgestructure.

    三、當弱電電纜與其它低壓電纜共用橋架時，應嚴格選用具有外屏蔽層的弱電系統的弱電電纜，避免相互干擾。

    3、Whentheweakcurrentcablesharesthebridgewithotherlow-voltagecables,theweakcurrentcablesoftheweakcurrentsystemwithexternalshieldinglayershallbestrictlyselectedtoavoidmutualinterference.

    從整個行業的發展趨勢來看，盡管電纜橋架行業競爭激烈，但濟南電纜橋架通過不斷的科技創新和技術攻關，已發展成為以優良服務為宗旨的國內電纜橋架設備制造企業，并憑借在電纜橋架設備領域的造詣和巨大投入填補了電纜橋架行業的新的生產線空白。

 Fromtheperspectiveofthedevelopmenttrendofthewholeindustry,despitethefiercecompetitioninthecabletrayindustry,Jinancabletrayhasdevelopedintoadomesticprofessionalcabletrayequipmentmanufacturingenterprisewiththepurposeofhigh-qualityservicethroughcontinuousscientificandtechnologicalinnovationandtechnologicalbreakthrough,andfilledthenewproductionlinegapinthecabletrayindustrywithitsattainmentsandhugeinvestmentinthefieldofcabletrayequipment.
